| Model | SJ-FMB1300 | SJ-FMB1450 | SJ-FMB1600 |
| Max. Paper size（W*L） | 1300*1300 mm | 1450*1300 mm | 1600*1300 mm |
| Min. Paper size（W*L） | 500*500 mm | 600*600 mm |
| Face paper thickness | 250-500 g/m²（standard paper board） |
| Flatness requirements on face paper | Curve height should less than 0.2 times of paper thickness |
| Requirements on film | Film ends should be less than 2 times of paper thickness |
| Bottom paper | A,B,C,E,F flute |
| Flatness requirements on bottom paper | Within 15/1000 mm |
| Corrugated paper deflection | Curve height should less than 0.2 times of paper thickness, deflection should be less than 2 times of flute height |
| Requirements on the height of corrugated flute | If there is difference between two flute, difference should be within 1/20 of the corrugated height |
| Diagonal requirement | Less than 3/1000 mm |
| Size requirement on face paper and bottom paper | Size of face paper should be 8 mm larger than that of the bottom paper |
| Laminate layers | Face paper + corrugated paper = 3 layers or 5 layers (total thickness less than 10 mm) |
| Precision | ±1.5 mm（according to the paper quality） |
| Speed | 100 m/m（theoretical value） | 90 m/m（theoretical value） |
| Production efficiency | 0-6000 sheets/h | 0-5000 sheets/h |
| Height of face paper pile | 1600 mm |
| Face paper table capacity | 1500 KG |
| Height of bottom paper pile | 400 mm |
| Total Power | 33 KW | 34 KW |
| Voltage | Three phase 380V |
| Efficient pressing length | 6000 mm |
| Conveying height | 250 mm |
| Adhesive medium | Corn starch glue |
| Collecting table size（W*L） | 1300*1300 mm | 1450*1300 mm | 1600*1300 mm |
| Collecting table capacity | 300 KG |
| Dimension（L*W*H） |
22000*2200*2500 mm (Subject to machine) |
22000*2400*2500 mm (Subject to machine) |
22000*2550*2500 mm (Subject to machine) |
| Machine Weight |
About 7.5 T (Subject to machine) |
About 7.8 T (Subject to machine) |
About 8 T (Subject to machine) |
